LiftLiner® RC

compact and agile design of the LiftLiner RC

LiftLiner® RC tugger train

For efficient order-picking and internal logistics



The LiftLiner® RC is the first tugger train on the market that transports a wide range of roll containers as well as dollies.

  • Carries up to 8 roll cages or dollies
  • Extremely compact design
  • Very good tracking accuracy
  • Loading and unloading from both sides
  • Enables a forklift free production environment
  • Safe, ergonomic and user-friendly load carrier handling

Download our flyer
LiftLiner RC tugger train

Benefits of the LiftLiner® RC

Improve your internal logistics

  • Reduces manual handling and handling costs
  • Implements a forklift free production environment
  • Eliminates time consuming sequencing
  • Reduces overall operating costs
  • Creates the fastest and most efficient routes through the facility
  • Streamlines Retail, E-Commerce as well as Parcel & Postal operations

Rollcage unloading LiftLiner RC

Innovative tugger train technology

  • Transports two roll cages or dollies per mother cart
  • Handles up to 500 kg per loading bay
  • Loading and unloading from both sides
  • Rooftop shape for easy and efficient handling process
  • Innovative tilting technology for safe and ergonomic use
  • Individual loading/unloading programs

customizable loading bays of the LiftLiner RC

Compatible with a wide range of roll cages and dollies

The LiftLiner® RC can transport up to 8 roll cages thus reducing the manual handling of already existing fleets.



Basic roll container dimensions:

  • Minimum width: 600 mm
  • Minimum length: 700 mm
  • Maximum width: 800 mm (without collision protection)
  • Maximum length: 860 mm

Please contact us for detailed information and an individual compatibility check!

Technical specification

A LiftLiner® RC consists of 4 loading bays (1 pair).

Max. load per loading bay 500 kg
Max. train length 2 LiftLiner® RC
Length (1 LiftLiner® RC) 4655 mm
Height 551 mm
Width 1024 mm
Weight (1 LiftLiner® RC) 760 kg
Max. train speed (1 LiftLiner® RC) 10 km/h
Max. train speed (2 LiftLiner® RC) 8 km/h
U-turn (2 LiftLiner® RC) 6000 mm
Ground clearance 0/60 mm

Selection of compatible products

2-sided A-frame nestable Compactainer®

2-sided Foldia®

Security Compatcatiner®
